  • Fin roller machine of radiator and condenser

Fin roller machine of radiator and condenser

Place of production: China

Feeding speed: 120 m / min

Total power: 4.5-7.5kw

Equipment air source pressure: 0.6MPa

Total weight of equipment: 1.8 tons




Machine Outline

The radiator fin roller machine is the core equipment for processing condensers, radiators, and intercoolers. Its total power is 3.5 kW, demonstrating strong power. More importantly, the fin drum mold’s exceptionally high manufacturing accuracy ensures the quality and cooling performance of the final aluminum fins.

Longitude is an essential parameter in the production process of fins. Servo motor counting allows for precise fin length control, thus meeting the needs of various heat sinks of different lengths.

This machine is over 5 meters long and has a production capacity of 120 meters per minute. Such high-efficiency equipment has significant advantages.

The radiator fin roller machine has become essential equipment in radiator factories due to its excellent stability and efficient production. It has demonstrated unparalleled strength in accuracy, efficiency, and application range.

Aluminum brazing furnace factory

Fin roller machine advantages

Our machine is one of the most advanced equipment in the automotive radiator industry. Compared with our competitors, this machine has the following advantages:

  1. Infinitely adjustable speed.

The motor is connected to the driver, and the PLC controls its operating speed.

Moreover, engineers can see the running speed of the motor on the touchscreen, and they can easily set the machine’s running speed through the touchscreen.

  1. Compact design.

This fin machine comprises a material feeding device, a fin forming device, a fin pitch control device, an intelligent cutting device, a control system, a lubrication device etc. Its design is very compact, which won’t waste valuable factory space.

  1. High-efficiency production.

This machine can produce at a speed of 120 meters per minute, which can meet the demand of most radiator factories.

The maximum production speed of our other machine is 300 meters per minute. If you need a faster machine, you can contact our engineers.

  1. High-precision manufacturing.

The roller mold for the fin machine is manufactured with high precision, and the size of the radiator fin it produces ranges from +0.02mm to -0.01mm in the factory.

  1. Low-cost maintenance.

Because the design of this machine is very compact, each part has undergone scientific design and distribution, and the roller mold of the fin has a modularized centralized design.

Therefore, maintenance costs can be almost ignored during their use, and some lubricating oil must be added monthly.

Fin Roller Machine Technical Data

No.ITEMDATA
1Total voltage3.5kw
2Fin Cut offservo motor control
3Device interactionTouch screen
4Servo motor controlEnglish
Chinese
5Warranty period12 months
6Fin typeLattice window
7Fin lengthAny size
8Fin height5-12 mm
9Fin widthMultiple sizes
10Delivery time46 days
Fin roller machine

Fin roller machine working video

Support and Services

  1. We accept customized services in the shape of “fin”, and we can meet your customized needs, whether you need blinds, sawtooth, waves, etc.
  1. We offer a 12-month repair service for this fin roller machine. We will provide free maintenance services during this period for any machine malfunctions.
  1. For anyone who purchases our equipment, we will provide spare parts for the machine, which can be used in the user’s factory for 3-5 years.
  1. Our engineers have a lot of work experience in the aluminum brazing industry, and we can provide brazing services to improve your quality and production efficiency.
  1. If your factory has an old machine, we can improve it so that we can continue serving you.
  1. Do you have any other machines in China? Our engineers can inspect this machine for you to ensure that it fully meets your requirements for size and quality.

FAQ

Q: Which markets have your fin machine?

A: This fin machine is competitive in price, beautiful in appearance, and fast in production. India, Pakistan, Brazil, Russia, Egypt, and Thailand have our fin machines.

Q: What is the delivery time of this machine?

A: The delivery time of this machine is 50 days.

Q: What is the control system of the radiator fin roller machine?

A: A PLC and a touch screen are used to control this fin machine’s control system.
