Extruded fin tube machine

Machine Overview

The extruded fin tube machine adopts roller extrusion, which is currently the most efficient metal tube forming process in production.

The device is designed with three symmetrically arranged roller molds that rotate at a constant speed to extrude aluminum material tubes continuously.

During the extrusion production process, as the roller rotates, the pipe undergoes plastic deformation under the pressure of the extruded fin tube machine roller, forming a pipe with fins.

The pitch size of the fins depends on the design of the mold, which users can replace to produce pipes with various fin pitch sizes that meet the technical requirements of different customers.

This type of extruded fin tube has good surface smoothness, a beautiful fin shape, and other characteristics. Highly favored by users in industrial applications

Extruded fin tube machine data

No.	ITEM	DATA
1	Circulating cooling	yes
2	Emergency stop	yes
3	Maximum length	20 meters
4	Power supply	380v
5	Voltage	50Hz
6	Tube diameter	14-70mm
7	Fin material	aluminum and copper
8	Inner tube material	Any material
9	Inner tube thickness	any diameter

Extruded fin tube machine advantage

1. The overall design simplifies the installation process, allowing users to place the machine in a suitable position and start working without requiring complex installation steps.

2. The control system design is simple and intuitive, allowing operators to quickly master operating methods without needing long-term professional training. This reduces the cost of human resources training.

3. The price of the Extruded fin tube machine is highly competitive, reducing users’ capital expenditures in the early stages of investment and helping to improve their return on investment.

4. A set of roller molds can adapt to producing fins with different diameters, increasing the machine’s versatility and applicability and improving production flexibility.

5. The built-in cooling system ensures a stable working temperature during long-term operation by circulating cooling, improving the machine’s durability and production efficiency.

Extruded fin tube machine working video

Fin tube machine advanced function

1. Special automation tools and a unique table with a conveyor belt are install at both ends of the machine. The motor drives the conveyor belt forward, allowing the machine to achieve fully automated production without supervision.

2. Industrial heat exchangers need many cooling tubes, such as spiral fin, and low-fin tubes. This Extruded fin tube equipment only needs to change the mold to produce these types of tubes, and the machine can produce spiral tubes faster.

3. This machine’s electric motor and gearbox are connected by flexible belts, a very mature technology that can smoothly output mighty power. If the belt is damaged, this type of belt can be easily purchased on the market.

Extruded fin tube machine cooling liquid

1. The fin tube generates a lot of heat during the extrusion production process, and the roller mold needs to be cooled on time; otherwise, the aluminum fin cannot be formed smoothly.

2. The saponification solution used in ordinary mechanical processing equipment cannot meet the cooling requirements of the extrusion tube machine, so users must purchase high-quality cooling liquid.

3. When using this Extruded fin tube machine for the first time, you need to check the running direction of the coolant pump. If it cannot deliver the coolant to the position of the roller mold, please change the position of the power cord.

4. Coolant can be recycled, but to protect the water pump’s long-term regular operation, the metal impurities in the filter screen must be cleaned promptly.
