Machine summary
The tube slot cutting machine is the production equipment of the automobile condenser. It can cut six tube at the same time. The tools for fixing aluminium tube are of flexible design. It can change different tools according to different aluminium tube ‘diameters to meet the factory’s multi size production,
The working platform of this machine can move in both directions along the X and Y axes. The servo motor drives and precisely controls the moving distance. The maximum error range is usually less than 0.01mm. This high-precision control can meet the production requirements of the condenser
The cutting blade is made of tungsten steel. The high hardness blade will cut aluminium tube without any burr. In addition, the machine is equipped with an automatic lubrication device. The lubricating oil can not only cool the blade, but also extend the service life of the blade
Advantages of tube slot cutting machine
- High speed production
This machine can cut 4-6 condenser aluminium tube each time, and the fastest production speed can cut 1000 aluminium tube per hour. This production speed can meet the requirements of large-scale production of condenser factories,
- Design that allows for blade replacement
As is well known, cutting blades are easily worn parts. This machine adopts a design that allows for quick blade replacement. Ordinary workers only need to spend a few minutes to replace a blade, and the downtime for blade replacement is very short
- Super safe operation
There are safety isolation doors on both the left and right sides of this tube slot cutting machine, as well as two isolation doors at the back. These isolation doors are made of organic glass material, which effectively prevents others from accidentally touching them during operation. The front of the machine is equipped with an infrared sensor, which stops immediately when workers come into contact with the work area, ensuring absolute safety
- Automatic lubricating oil supply
This machine uses volatile oil lubrication. Before the machine cuts aluminium tube, it will automatically spray a small amount of lubricating oil. This spraying process is automatic operation of the machine without manual intervention,
- Fixed tools have error prevention function
The head tube of the condenser has front and back sides. Our equipment has error proofing function. If the workers install aluminium tube incorrectly, the machine will give a warning, and it will not start cutting aluminium tube. This design can reduce the waste of materials
Technical parameters of tube slot cutting machine
- Machine function: Pipe groove cutting
- Scope of application: condenser head tube
- Number of pipe slots: 4-8
- Tube diameter: 15-60mm
- Fixed tool: design can be changed
- Maximum length of tube: 1000mm
- Cutting motor: 2.2kW
- Size control: formula preset
- Workbench: Driven by servo motor
- Tolerance range: 0.01mm
- Operation method: manually release tube
- Lubricating oil type: volatile oil
- Tool tightening: Pneumatic
- Tube specification: D type, O type
- Equipment weight: 1.5 tons
- Power supply: 380V/50Hz
Other types of condenser machines
Fin stamping machine of condenser and heat exchanger
Machine outline This high-speed fin stamping machine is an ideal fin production equipment, widely used in the automotive, household appliances, and industrial heat exchanger industries, The working principle of this machine is to achieve high-speed…
Intercooler core assembly machine
Equipment Overview The intercooler core assembly machine is a device uses to produce intercoolers in trucks. Its primary driving method is a servo motor, and the cylinder is an auxiliary drive. This machine adopts a…
condenser header opening machine
Product Description The condenser header opening machine is special equipment for adding the fixed length round aluminum tube by pressing and punching the core collecting pipe of the parallel flow condenser. It is one of the essential equipment…
Aluminum tube bending machine for condensers and evaporators
Machine Overview The aluminum tube bending machine is production equipment for automotive evaporators. It straightens the microchannel aluminum tube of the coil, bends it into an S shape, and then cuts it It is a…
Tube slot cutting machine work video
Advanced functions of tube slot cutting machine
- Size preset function
Because there are many models of automobile condenser, the size of almost every automobile brand’s condenser is different. In order to meet the production needs of all condenser, this pipe slot cutting machine uses the function of size presetting. The engineer can set the size required for cutting through the touch screen, and store these sizes as an independent formula. In the future, the same aluminium tube can be produced with one key
- Super simple installation process
This tube slot cutting machine is an independent whole, and there is no complicated process to install it. Engineers only need to place the machine in a suitable location in the factory, connect the power supply and compressed air, and it can be used normally
- The touch screen has multiple languages
In order to meet the needs of different customers, we have set multiple languages for the touch screen, making it very easy for workers to quickly use this machine. Usually, the touch screen is built-in with Chinese and English, and we can also provide other languages for you, such as Russian, French, Spanish, etc
- Lubricating oil alarm device
Due to the installation of the lubricating oil tank under the machine, workers cannot see the lubricating oil during normal production. Therefore, we have installed a sensor for this oil tank. If the lubricating oil reaches the lower limit, the machine will automatically alarm and the touch screen will display “Add lubricating oil”
Summary
This tube slot cutting machine is specially designed for the production of automobile condenser. It has intelligent control and high-precision production capacity. It is one of the most important equipment in automobile condenser production plants at present,
If the production capacity of your condenser factory is greatly increased, you need a machine urgently to improve your production efficiency, or the existing machine precision cannot meet your requirements, then this machine will be your best choice
If you would like to learn more details about this machine, you can send us an email through the contact form below, and our engineers will reply to you soon
