Fin forming machine of the plate and bar heat exchanger

Metal thickness: 0.05-0.5mm
Production speed: 144 times /min
Motor power: 7.5 kW
Delivery time: 40-42 days
Fin mold: replaceable
Production type: continuous automatic

Machine Overview

This is a rock solid fin forming machine that can produce fins for almost any heat exchanger you can imagine. It is a universal fin-forming press machine that allows for the operation of multiple sets of tools to produce a variety of fins to meet your production needs.

In normal production processes, a set of molds can produce various raw materials for different metals, such as stainless steel, aluminum, copper, titanium alloys, iron, and other metals.

The fin forming machine adopts a 4-column design, which can achieve smooth and high-speed operation to improve the quality and production efficiency of the heat exchanger fins.

fin forming machine

Machine data

1Metal thickness0.05-0.5mm
2Max Fin width300mm
3Fin height1.5-45mm
4Fin lengthany size
5Motor power7.5kw
6Power supply380V
7Production typecontinuous automatic
8Fin moldreplaceable
9Delivery time40-42 days
10Production speed144 times/min
corrugated fin forming machine
fin forming machine

Fin forming machine control system

1, All parts come from internationally renowned brands Siemens and Mitsubishi, ensuring high quality and reliability of the system

2, The 7-inch touch screen is used for human-computer interaction, providing a convenient operating interface with two languages: English and Chinese, making it easy for operators to choose according to their needs

3, The fin forming machine has highly automated characteristics and can perform continuous production without manual intervention, achieving an unmanned production mode.

4, Allow users to preset the production yield and fin size.

Users can preset the required production yield and fin size through the touch screen, and the system will automatically adjust the production process based on these settings

Fin forming machine manufacturer factory video


Q: Can this machine produce aluminum fins with a width of 110mm?

A: Of course, our machine has a maximum width of 300mm and can produce two 110mm aluminum fins at the same time.

Q: What is the delivery time for wave type fin molds?

A: The delivery time for this mold is 25 days.

Q: Can it produce stainless steel material with a thickness of 0.12mm?

A: The maximum thickness of stainless steel material is 0.2mm.
